working principle:
the fan draws the feeder tank to form a negative pressure, and the suction material enters the feeder tank through the conveying pipe. the material and air are separated by the filter element, and the clean air is emptied through the fan. when the material is gathered to the designated material level, it is discharged from the lower part of the feeder. it is a kind of conveying equipment that transmits bulk materials by means of vacuum suction.
application scope:
the product is especially suitable for conveying powder, widely used in chemical, ceramic, plastic, and other industries, for feeding equipment;
in the plastic industry, it is often used for feeding extruders, hoppers, silos and other equipment.
service conditions:
service temperature: - 10 ℃ - 80 ℃
material science:
contact with material: ss304
optional accessories:
fan bypass device
auxiliary discharge device (for materials with high adhesion)
type of discharge valve: flap discharge valve or pneumatic cone discharge valve
